Quick Fuel Q-1050-b2 1050 Cfm Gas Supercharger Blower Clear Aluminum Carbs on 2040-parts.com

US $1,776.99
Location:

Lakeville, Minnesota, United States

Lakeville, Minnesota, United States
Condition:New Manufacturer Part Number:Q-1050-B2 CLEAR Part Brand:QUICK FUEL Warranty:Yes Country of Manufacture:United States Country/Region of Manufacture:United States










YES IN STOCK & YES WE COMBINE SHIPPING



NEED ITEM INFO? 952-469-3219

CARBS ARE CLEAR ALUMINUM IN COLOR YOU ASK FOR THEM & YOU GOT THEM



PAY BY 4:00 PM CST M-F & WE WILL UPS THE SAME DAY THX



Q- Series Carburetor 1050 CFM BLOWER GAS DRAG RACE  CARBS- Built for the ultimate blend in performance and drive-ability.  with all the tuning you features you would expect from a carburetor that's ready to race. Street duty is no sweat for the Q-Series with it's built in 4-corner idle.

~ Aluminum main body, and fuel bowl with QuickSet sight windows on both sides make for easy float adjustment

~ Billet metering blocks and throttle body ensure leak and porosity-free sealing between circuits

~ Each carburetor is hand-assembled and engine tested in the USA!

Q-Series Carburetor 1050 CFM 2x4 Supercharger

Whether you're putting a big ol' Roots-style blower on a street rod or a race car, Quick Fuel's 2X4 blower carbs will make life easier. These carbs include boost-referenced power valves, and the specially designed throttle body features built-in channels to guide excess fuel from the top of the throttle plates, around the throttle shafts, and back into the intake manfold to lessen the possibility of fuel leaking onto the intake.

Quick Fuel Technology's ready-to-run 2x4 Blower Carburetors will deliver the air and fuel your engine needs to make race-winning power. Whether you are driving a custom street rod or a full on racecar, these all aluminum 2x4 blower carbs are the right performance choice.

QFT's 2x4 blower carbs feature shortened throttle levers for clearance. The QFT engineers added an external vacuum reference tube for the power valve to connect to the intake manifold with a hose. This allows the power valve to see only positive pressure at Wide Open Throttle, eliminating the possibility of the power valve closing if the supercharger starts to "out run" the carb.

The 2x4 blower carbs have all the vacuum ports removed to avoid any plugs or hoses blowing off under boost conditions. The specially designed throttle body features built in channels to guide excess fuel from the top of the throttle plates around the throttle shafts and back into the intake manifold. This lessens the possibility of the fuel build up running out the throttle shafts onto the hot intake manifold.

BOTH CARBS ARE CLEAR ALUMINUM COLOR THANKS





62dc3881-dfd3-3e06.jpg picture by richiedd


Q- Series Carburetor 1050 CFM GAS DRAG RACE BLOWER SUPERCHARGER CARBS PART #Q-1050-B2

carb comes with base gasket, air cleaner gasket, & 1 to 1 silver link, 1 black link for 60% primary before secondary opens.

 Q Series Carburetors Secondary Linkage Adjustment

  • Super Progressive
  • Black Link
  • Top Hole


Lower slot 60% primary before secondary opens.

  • Medium Progressive
  • Gold Link
  • Top Hole


Top slot 40% before secondary opens. This is the standard linkage position for most applications.

  • 1=1
  • Silver Link
  • 3rd Hold
  • Top Slot

Using the alternate lower hole and top slot, the silver link provides a even opening ratio for both the primary and secondary throttle shafts.

PRIMARY MAIN JET 86
SECONDARY JET 94
IDLE AIR BLEED 70/70
HI SPEED BLEED 25/25
PRI NOZZLE 37
SEC NOZZLE 37
NEEDLE & SEAT 120
POWER VALVE 3.5



NEED ITEM INFO? 952-469-3219 THANKS RICH

 (TOP PLATE NOT INCLUDED)

WE DELIVER!!!!, BIDDER PAYS FIXED UPS SHIPPING $0 S/H, AK, HI, PR, WILL PAY ACTUAL SHIPPING CHARGE,  IF YOU NEED TECH HELP FOR PICKING A CARB, TECH HELP ONLY( NO ORDERING)-----> 270-793-0900  BE SURE TO CHECK OUT MY OTHER AUCTIONS IN THIS CATAGORY FOR OVER 1000 MORE CARBS,  CLICK MY STORE TAG FOR MORE------------->THANKS
