Find or Sell any Parts for Your Vehicle in USA

Core / Hurst Shifter Base For T56 From Cobra Viper Ram Falcon 6 Speed Trans Swap on 2040-parts.com

US $109.00
Location:

Sugar Land, Texas, US

Sugar Land, Texas, US
Returns Accepted:ReturnsNotAccepted Manufacturer Part Number:3910040 Interchange Part Number:3915072 Other Part Number:391-0040 Part Brand:Core / Hurst

PLEASE!! Read the entire description before purchasing - this shifter may not fit your trans!

*** This listing is ONLY for people doing custom installations & trans swaps.  It is not intended for any OE application (see my other listings for complete kits where available). ***

Core / Hurst short throw shifter base that replaces the stock shifter (at the tail location) on the following models with T56 6 speed:

  • 1992-2007 Dodge Viper
  • 2000 Mustang Cobra R
  • 2003-2004 Mustang Cobra
  • 2004-2006 Dodge Ram SRT-10
  • 2004-2008 Ford Falcon & FPV BA-BF (Australian)
  • 2008-2013 Ford Falcon FG XR models (Australian)

Also fits TR6060 found in:

  • 2008-2010 Dodge Viper
  • no other TR6060 (see my other listings for forward mount)

This shifter base mounts on a 4-bolt pattern that is approximately 2.88" wide x 3.44" long and the center of the stub pivot ball is approx 1.25" below the flange.  It only fits in the tail location where the OE shifter is mounted.  For forward mount conversion, see my other listings.



Does NOT fit the following (these applications use the "forward location" mount, see my other listings):

  • 2004-2007 Cadillac CTS-V
  • 2006+ Holden Commodore VE
  • 2007+ Mustang GT500
  • 2009 Pontiac G8 GXP
  • 2009+ Challenger (tail location - see special listing)
  • 2009+ Cadillac CTS-V
  • 2010+ Camaro

    Does NOT fit the following (these applications use a tail mount shifter with a longer bolt pattern, see my other listings):

  • 1993-2002 Camaro / Firebird
  • 2004-2006 Pontiac GTO & Holden Monaro
  • 2005-2006 Chevy SSR truck



    This is a custom shifter base composed of readily available Hurst Billet Plus component set (supplied by Hurst) inside a custom housing (not produced by Hurst, but 100% made in USA).  It functions like any regular Hurst Billet Plus shifter, but in a configuration Hurst does not offer.  Obviously throw reduction is subject to the OE equipment being compared, but this shifter was designed to yield about 35% throw reduction over an existing direct fit OE unit.  I ALSO OFFER A "SST" SHORTER THROW UNIT ~45-50% REDUCTION FOR $10 MORE (best for taller sticks)- EMAIL TO REQUEST.  You can mount any Hurst bolt-on stick to this base.  I sell many in my other listings.  This base includes mounting hardware, dust boot, and instructions.  It does not have stops and does not need them; all modern internal rail trans have internal stops.  However if you prefer, stops can be added for $12 more, email me to request.

    Fulcrum options:

    • 2.53" fulcrum (default offered in this listing) is best for 8-10" stick length.  Lower stick mount bolt hole is 3.07" above base flange.
    • 3.03" fulcrum ($10 extra) for 10"+ stick length.  Lower stick mount bolt hole is 3.57" above base flange.
    • 3.22" fulcrum ($15 extra) for 10"+ stick length, with higher stick mounting point to fit dust boot under stick.  Lower stick mount bolt hole is 4.58" above base flange.
    • 3.66" fulcrum ($20 extra) is an option for 14"+ stick length, but stick mounts at 14 degree angle toward left.  Lower stick mount bolt hole is 5.38" above base flange.
    • For all optional fulcrums, please EMAIL PRIOR TO PURCHASE!

    If you are doing a trans swap and not sure which Hurst chrome stick you need for your custom application, please see:  http://www.core-shifters.com/hurst2004sticks.pdf

    This Core Shifter shares many of the same superior features & components found in Hurst Billet Plus Shifters, integrated into a unique, exclusive base assembly:



    • Forged heat-treated billet steel gear selector
    • Precision-ground stainless steel pivot ring
    • Self-centering cross-gate bias springs with heat treated spring seats
    • Glass-reinforced polyamide pivot cup insert with steel wear clips
    • Rubber oil control seal with steel retaining ring
    • 6061-T6 extruded aluminum housing with Spirolox steel support ring
    • Phosphate-coated laser-cut steel base-plate and cover
    • Vibration-resistant serrated flange head steel retaining bolts
    • Optional adjustable positive gear stops (extra charge)
    • Rubber dust cover boot
    • High quality and outstanding value!



    SEE MY OTHER LISTINGS FOR SHIFTERS, STICKS, KNOBS, & "HURST EQUIPPED" EMBLEMS!
