Diesel Caterpillar Marine Engine Panel on 2040-parts.com

Panel Material: UV Resistant

Fog resistant  Marine Grade Gauges:

1. 4000 RPM Programmable Tachometer with Digital Hour Meter 7 character LCD display
2. 250ºF Temperature Gauge
3. 80 PSI Oil Pressure Gauge
4. 12 VDC Voltmeter
5. Fuel gauge

Tachometer Hourmeter features:

• Electronic tachometers work by counting pulses generated by the ignition system, alternator, tach signal generator or magnetic pickup sender.
• Hooked up to +12vDC, Ground and your signal source.
• updates in .1 increments
• 0-999999.9 Hours
• 7 character LCD display
• The analog looking dial and pointer sweep is driven by a digital stepper motor providing greater accuracy and dependability than magnetically wound gauges. You get the advantages of digital instrumentation with the look and feel of the analog gauges.

Sealed Ignition Key Switch by Littelfuse Features:

• Sealed Key Switch With Anti-restart
• Set of keys included
• With anti-restart. [So you are prevented from double cranking the engine]
• 10A at 12V
• Four positions: Accessory – Off – Ignition/Accessory – Start. Spring return to Off.
• Keyswitch is constructed from engineering thermoplastic and is fully sealed using O-rings and ultrasonic welding to protect switch to ip67(with connector installed)
• Plastic facenut and nickel-plated brass backing nut. Supplied with two matching keys. With protective key boot.
• Sealed to IP67

Marine Grade Wire Features:

• Copper tinned
• flexible
• spark-proof
• wired with ABYC Color code
• 10″ to 12″ Pigtail Harness connected to 12 position terminal strip

• Marine grade push button Switch (Engine Stop or Pre-heat)
• 2 tone Pizzo Siren Alarm
• Senders and Accessories not Included
• Engraved with Engine Name
