New, opened but never used or installed

The Signal Vehicle Products SS741MG is two sirens in one.  The MAGNUM™ has two separate modes of operation, each offering its own distinct tones. Each of the two isolated amplifiers operates one 100 watt speaker, for a total of 200 watts of output in one box.

The remote control head is perfect for dash or panel mounting with use of the telephone type connection to the amp box. LED speaker diagnostics allow quick troubleshooting. Rotary switch selectable operating modes are Wail, Yelp, Hands Free, Phaser, Manual, Alert, and Radio. Push buttons operate Manual and Air Horn. Operating tones are Wail, Yelp, Air Horn, Phaser, Manual, and Two-Tone.

The SS741MG also features positive or negative switching for AUX and Park Kill inputs and is protected against speaker shorts with a self-resetting circuit and a high & low voltage shutdown feature. This unit also features jumpers for option selections, public address override, and separate volume controls for the radio repeat and public address functions.

Features:

• Two isolated amplifiers in one box
• Self-resetting circuit protection against speaker shorts
• Integrated public address microphone
• Park Kill input
• Auxiliary input
• Positive locking wiring harness included
• High and Low voltage shutdown protection
• Drives one or two 100 Watt speakers
• Includes mounting hardware, PA microphone, mic clip and wiring harness
• 6 Siren tones:

Specifications:

• Output: 100 Watts or 200 Watts (1 or 2 Speakers)
• 10-16 Volt DC
• Current draw: 16 Amps (per Speaker)
• Measures: 2-3/4"H x 6-1/4"W x 1-1/2"D (Control Head), 2-1/2"H x 7"W x 7-1/3"D (Amplifier Box)
• Weight: 9 lbs.
