Quick Fuel Q-750-e85 750 Cfm E-85 Carburetor Black Carb & Line Kit Must See!! on 2040-parts.com

US $840.95
Location:

Lakeville, Minnesota, United States

Lakeville, Minnesota, United States
Condition:New Brand:QUICK FUEL Country/Region of Manufacture:United States Manufacturer Part Number:Q-750-E85 BLACK Country of Manufacture:United States Warranty:Yes Part Brand:QUICK FUEL





YOU ASK FOR THE BLACK & YOU GOT THE BLACK

ALL NEW & IN STOCK FROM QUICK FUEL   Q-750-E85 DRAG RACE CARB

CARB COMES WITH A FREE BLACK FITTING #6 BRAIDED LINE KIT YOU CAN FEED YOUR MOTOR WITH 1 #6 FUEL LINE OR USE A HOSE & CLAMP

OR YOU CAN HAVE A RED OR BLUE LINE KIT,  YOUR CHOICE JUST ASK





MEAN GREEN! 750 CFM E-85 designed specifically for E-85 fuel , this carburetor is packed with all the features you've come to expect such as billet metering blocks, billet booster inserts, light-weight aluminum fuel bowls with sight windows and fuel inlets. External linkage makes for easy changes in opening ratios without having to remove or disassemble the carburetor. Stainless needles and seats, accelerator pump screws, along with GFLT® diaphragms and Nitrophyl® floats prevent carburetor corrosion.

Q- Series Carburetor 750 CFM DRAG RACE  E-85 mechanical secondaries - Built for the ultimate blend in performance and drive-ability. This carburetor features jet extensions and a notched float with all the tuning you features you would expect from a carburetor that's ready to race. Street duty is no sweat for the Q-Series and 4-corner idle.

~ Aluminum main body, and fuel bowl with QuickSet sight windows  makes for easy float adjustment

~ Billet metering blocks and throttle body ensure leak and porosity-free sealing between circuits

~ Each carburetor is hand-assembled and engine tested in the USA!


Q- Series Carburetor 750 CFM E-85 DRAG RACE PART #Q-750-E85

carb comes with base gasket, air cleaner gasket, & 1 to 1 silver link, 1 black link for 60% primary before secondary opens.

  Q Series Carburetors Secondary Linkage Adjustment

  • Super Progressive
  • Black Link
  • Top Hole


Lower slot 60% primary before secondary opens.

  • Medium Progressive
  • Gold Link
  • Top Hole


Top slot 40% before secondary opens. This is the standard linkage position for most applications.

  • 1=1
  • Silver Link
  • 3rd Hold
  • Top Slot

Using the alternate lower hole and top slot, the silver link provides a even opening ratio for both the primary and secondary throttle shafts.

PRIMARY MAIN JET  80
SECONDARY JET  90
IDLE AIR BLEED  65
HI SPEED BLEED  28
PRI NOZZLE  35
SEC NOZZLE  35
NEEDLE & SEAT  130
POWER VALVE  4.5

CHECK OUR FEEDBACK WE DELIVER!, NEED MORE INFO CALL US ----------> 952-469-3219 THANKS RICH,

BUYER PAYS $00 S/H/, HI, PR, AK, WILL PAY ACTUAL SHIPPING, NO COD, I UPS ONLY, IF YOU NEED TECH HELP FOR PICKING A CARB, TECH HELP ONLY( NO ORDERING) -----> 270-793-0900 CLICK ON MY STORE TAG FOR MORE DEMON CARBS------------> THANKS


DO YOU HAVE A TIRED HOLLEY OR EDELBROCK CARB? THEN GIVE QUICK FUEL A TRY!!
