The MOM8-A is a rugged and reliable system which, when properly maintained and serviced, will provide sailors with the most advanced aid in the recovery of a person overboard.
With the introduction of the original Man Overboard Module System in 1978, Survival Technologies Group set new standards in the design of equipment to aid in the recovery of a person overboard. Continuously improved and upgraded over the years since its introduction allows the latest version of the MOM8-A to maintain its leadership in Man Overboard equipment.

Features:

• The MOM8-A is a completely self-contained system consisting of the canister (complete universal mounting hardware included) with an inflatable horseshoe shaped buoyant device, inflatable locator pylon, and a self-opening sea anchor, all packed in the canister and ready for instant deployment
• Both inflatable devices are fully deployed and inflated within 7 to 10 seconds after deployment
• The MOM unit is mounted on the stern pulpit either directly over the stern or on the port or starboard quarter depending on the boat's configuration
  • Located on the top of the canister is a Deployment Handle which when pulled opens the bottom of the canister and allows the inflatable devices to automatically inflate while falling into the water
  • The canister is positioned on the stern pulpit in a way which allows free-fall into the water
• When inflated, the ballasted Locator Pylon has a 6-foot waterline height
  • Located on top of the Pylon is a water-activated, Lithium-powered, flashing light with 5 years of life
  • The light can be seen nearly a nautical mile under normal night conditions
  • The Pylon has (2) SOLAS reflective panels to aid the boat's search
  • The Pylon is tethered to the inflatable horseshoe-shaped buoyant device capable of supporting a 250 lb. person with high freeboard
    • Freeboard is measured by the distance of the victim's mouth above the water while afloat in the horseshoe
• The horseshoe is placed under the arms and there is a quick-connect adjustable belt for full encirclement
  • Attached to the horseshoe are two Lifting Straps with stainless steel 1" D- Rings
• The Lifting Straps enable the person to be lifted aboard while remaining in the horseshoe
• Tethered to the horseshoe is a 16" diameter, ballasted, self-opening Sea Anchor to reduce downwind drift.

Specifications:

• Canister:
  • 14.5"H x 11"L x 4.25"W
  • Weight - 22 lbs. packed
  • Material - Molded Polypropylene
  • Color - White
• Horseshoe Inflation Device:
• Capable of supporting a 250 lb. person with high freeboard
• Material - 420D Urethane-Coated Nylon
• Buoyancy - 40 lbs. Inflated
• Color - High Visibility Yellow
• CO2 Cylinders - 38gr. - 3/8" thread
• Lifting Straps:
  • 1" wide nylon webbing with 2 SS D-rings
• Locator Pylon:
  • Waterline Height - 6' height
  • Material - 200D yellow urethane-coated nylon
  • Color - High Visibility Yellow
  • Reflective Panels - 72 sq. inches
  • Auto Light - 8-hr. Flashing
  • Ballast - 8 lbs.
• Inflation: 33gr. CO2 cylinder
• Sea Anchor: 16" diameter
• Tethers: 3/8 Floating line

Kit Includes:

• Rail Clamps: 7/8", 1", 1-1/8", and 1-1/4"
• All Necessary Stainless Nuts, Bolts and Fast-pins
