Gps In Dash For Mercedes E Class. C Class Clk Class on 2040-parts.com

7 TFT high-resolution Digital LCD Monitor(800*480 resolutions)
Built-in GPS(WinCE 6.0 Core).
Double-zone Funtion: driver can listen to music while viewing the map.
Touch-Panel Control
GPS secondary planet navigation,3D virtual Navigation
DVD/Dnicx/MP4/MP5/VCD/SVCD player
Super Sensitive FM/AM (RDS)
Built-in Bluetooth function.
SD CARD/USB slot input
Volume/bass/treble/bal/fad trumpet electronics
Super Bass output 5.1Mode Built in 4*45W(or 5*45W)Amplifier
AV input/output
Parking rear video input(when you startup reverse,the LCD will show the backsight signal)
OSD language:English

(1)FM/AM Radio Function:
The Built in High sensitive digital Tuner will make the Signal stronger and better sound quality, in which you can easily search and store up to 32 your favorite radio channel on it.

(2)Bluetooth Function:
The Bluetooth wireless technology brings you the convenient to answer a phone call. To use this, you need to match the mobile phone with the car audio first and make the Bluetooth is connected. So whenever there is a calling, just touch on the Monitor screen or steering wheel control (depending on your car) to answer the phone car.
Besides that, through the Bluetooth wireless technology, you are able to play any music from your mobile phone. Please take note that, ADP2 is required on the Mobile Phone.

(3)USB Drive (Pen Drive)/SD Function:
Just click on USB/SD icon on the main menu, you can be easily browse pictures and music from the USB port or SD Card if connected. (Cannot support hard disk)

(4)Auto rear viewing System:
Parking and reversing will be very easy and safe with this rear viewing System. When driver is reverse or the gear position at R, he/ she can look on the monitor display to view the rear side.
For your information, the rear view camera is not included, which you need to buy in additional.

(5)GPS/Navigation (Global Position System):
GPS is the abbreviation of Global Position System. It is a navigational system involving satellites and computers that can determine the latitude and longitude of a receiver on Earth by computing the time difference for signals from different satellites to reach the receiver. In the first GPS receivers this information was made visible on a small LCD screen. A small computer program in the receiver translated the information about subsequent positions into dots on the screen. This way you can see where you came from and where you actual are, as well as the track that you followed to come to your actual position. Once you move, the system can also calculate the direction you move to, by comparing subsequent positions. If you project your direction over a longer distance, you can even see where you are heading.

(6)Dual zone
Driver can listen to the music while using GPS navigation at the same time. If you are playing music and hit the Navi button, it will switch to GPS while still playing your music. While driving to wherever the destination is, the music will cut out for a second while your GPS instruction plays (ie.Turn left in 100 feet), then it will go back to your music.

(7)Steering wheel control:
Drivers can directly control DVD player while driving on the road via the Steering Wheel Control Function such as adjust the volume, Next, back depending to the original car Steering wheel control. With this function, drivers can intently focus straight ahead, which will make the driving safer.

(8)IPod Control:
The IPod Control enable you to connect your iPod and play the Songs, but due to current technology , the car player display might not show the total songs list from your iPod, and it might not charging your iPod while connected.

(9)HD screen ready
High Definition, With high resolution 800x480 pixel .


Product information
Car Model Special Car DVD player For Mercedes-Benz R300 R350

Item Name 2 Din HD Car DVD with GPS/ Blue tooth/I-POD control/USB/SD/Radio/Amplifier



ARM11 solution
Dual Zone function, listening to Radio/watching GPS image in the same time
Display 7 inch 16:9
800*480pixes digital TFT
DVD Section:
Disk Compatibility Supports DVD/VCD/CD/MP3/MPEG4/CD-R/WMA/JPEG
Media Compatibility Supports DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP4(DIVX)/VCD/SVCD
GPS Section:
Operation system Windows CE6.0
Supported maps Igo, Route66, Tom-Tom, Supports 3D Maps
GPS Baud Rate=9600, Com Port=2
CPU Intel samsung S3C2451 Processor
Main Frequency 533MHZ
SDRAM/FLASH 1GB/128 MB
MAX Memory supported 16G
Orientation presicion <15m
Refurbish frequency 1HZ
Length of antenna 5M
Chipset SiRF STAR III
GPS antenna frequency 1575.52MHZ
Language English
Bluetooth: A2DP
Microphone built-in
Phone book

Radio: AM Frequency Range:
522-1620 (Europe/China),530-1710 (America)
FM Tuning Range:
87.5-108 (Europe/China), 87.5-107.9 (America)
30 stations storage
Usable Sensitivity 5dBV(S/N=30dB)
Amplifier 4*45 Watts
Audio & Video
Input/Output: Aux Video Input 1
Aux Audio input 1
Video Outout 2
Audio Output 4 ( FR/FL/RR/RL)
Camera input 1 (Auto rear view)
Radio Aerial input 1
TV Antenna input no
I-POD Input 1
Audio Section:
1) Rated Output 4ch*3W
2) Maximum Power Output 4ch*50W
3) Rated Speaker Impedance 4
4) Pre-AMP Output Voltage 2Vrms
5) Pre-AMP Output Impedance <220
7) Video 1 Vp-p(75)
8) Audio 500mVrms
Support Audio type MP3/PCM/WMA
Support Video Type ASF/AVI /WMV /DIVX
Port 1 USB port
2 SD card port, 1 for Music/movie, 1 for GPS
Can bus With CAN BUS
Package: 1 x Multimedia DVD Player
1 x User Manual ( English )
1 x GPS antenna ( GPS function )
1 x I-Pod wire ( I-POD function )
1 x USB wire ( USB function )
1 x Remote control
1 x Install tool
