Lada Niva / 2101-2107 Wiper Relay With Pause Regulation (Memory)

Principle of work and installation instruction.

Please don't use this instution on your website without my agree!!

Lada Niva / 2101-2107 Wiper Relay With Pause Regulation (Memory)

http://ladapower.com/index.php…

----------------------------------------------------------------------------------

This relay have two great advantages.

1) Automatic turn on wiper engine when you add water to your windshield.

When your wiper engine turned off and you use washer pump to add some water on your windshield - you don't need to turn on wiper engine manually. This relay will turn on wiper engine to made 3 cycle or sweeps.

Here you can see on video how this work.

https://www.youtube.com/watch?v=Sp-9eKkz-IQ

-----------------------------------------------------------------------------------

2) Wiper sweeps pause regulation.

Lada Niva and Classic Lada have 3 positions of wiper speed.

1) Turned Off

2) Intermitettent

3) Continuous

Very often when small rain starter - position #2 have very big pause between wiper sweeps. And you have to do extra swips by turn on / off faster by hand.

Now you can adjust time between sweeps from 2 to 45 seconds.

How to tune pause? This is very easy!

Step-by step.

1) Turn on "Intermitettent" position

2) Wait for only 1 wiper speep cirle (right and back to left)

3) Turn back to "Turned Off"

And from this moment started time count. For example if you are waited 20 sec before step №4 - you will have 20 sec pause between wiper sweeps. Etc. with any time you like.

4) Turn on "Intermitettent" position

So you can see - you can tune up pause even if you wait for the green light on the crossroad.

Here is video you can see.

https://youtu.be/Sp-9eKkz-IQ?t=10m8s

-----------------------------------------------------------------------------------

3) Installation.

Installation super easy without electric education.

Don't need any extra cables.

You need to connect wiper sockets between tell-tales switch and wire loom. (Picture attached.)

This is two clicks of 6 pin sockets and all is ready.

And now you need to connect one free white cable from relay to pink wire of the washer fluid pump. (Picture attached.)

To do this in kit with relay you will have red connector. For easy work. (Picture attached.)

This is all.
