Perkins Marine Engine Instruments Panel Custom Made W/ Wiring Harness Terminal on 2040-parts.com

US $499.99
Location:

Torrance, California, United States

Torrance, California, United States
Condition:New Brand:AC DC Inc. Country/Region of Manufacture:United States Manufacturer Part Number:B-PERK-WH-10X6 Teleflex,Farria,Hewitt Ind:Computer design U.S.A. made UPC:853262004367


Perkins Marine Instruments Panel
(Custom Professionally made after market panel)

Dimensions: 10 3/4" x 6 1/8"

Perkins Marine Engine Instrument Panel – Available in Black or White  Check out my other items!

  • Marine grade push button Switch (Engine Stop or Pre-heat)
  • Marine grade Ignition key, Off-on-start
  • 15A (ign), 30A (sol), 7A (pre-heat/ or output for Glow Plug relay) @ 12 Volts DC
  • 2 tone Alarm Pizzo Siren
PLEASE READ BEFORE YOUR PURCHASE!
This Volvo Penta Engine Instrument Kit is made with The Magnetic Pick-up Tachometer that hooks up to a magnetic pickup sensor which counts gear teeth. Here neither of the wires is grounded to block. They are both routed up to the tachometer as a twisted pair. One hooks to the signal terminal and the other to the ground terminal on back of the tachometer. The switch is set to the approximate number of teeth that the sensor sees on each engine revolution. Another adjustment on the back allows fine tuning to the exact number of teeth.
The label is marked in ranges generally from the 80 to 200 gear teeth.
This Programmable tachometer will also function with a tachometer signal generator which is spun by the engines' mechanical take-off. One of the signal generator's wires in grounded to the engine and the other is connected to the tach's signal terminal.
Please check the type of RPM signal your engine has, we have all three tachometers available for purchase.


ACDC Inc™ by Faria® Gauges – Fog Resistant w/ Stainless Steel Bezel

  • Programmable Tachometer 4000 RPM with Programable Digital Hour Meter
  • 250 F Temperature gauge
  • 80 PSI Oil Pressure gauge
  • 12 Volt meter
  • Fuel Level gauge
Easy To Install
Marine Grade Wire
US Coast Guard Color Code

Marine terminal bar with 12 circuits:

1. Light Brown- High Temperature Alarm

2. Light Blue – Low Oil Pressure Alarm

3. Purple- Ignition

4. Red-12 Volt Supply Battery, must be fused

5. Orange- Instrument Light (Looped to Ignition)

6. Pink – Fuel Gauge Signal

7. Dark Brown -Temperature Sending Unit

8. Dark  Blue-Oil Pressure Sending Unit

9. Gray-Tachometer Signal (from Alternator)

10. White- Push Button (Preheat)

11. Black-Ground 12 Volt

12. Yellow-Crank/Start


Sending Units Not Included
