Digital Delay Elite 625 Delay Box With Dual View Dial In Controller 1111br-b on 2040-parts.com

Digital Delay Elite 625 with built-in Dial controller, DUAL VIEW BOARD, Black Case with Red Screen

With Your Choice Of LED COLORS Red, Blue, Green, Orange and White

One Black Display Board with DUAL View LED

Automatically updates your Dial Display board every time you change Your Dial on the Elite 625.

No need to enter Your Dial a second time on another unit.

The Elite 625 has all the features of the Elite 600, plus some new features. Including our Set and Go push-button mode which is similar to Z-Force* - the press of a button (SET) sets the Transbrake and then on the press of a separate second button (GO) starts the delay timing - and the ability to directly control any of our V2 Dial Display Board.

Features / Specifications

CrossTalk Compatible

Same dash cutout as Mega 400, Mega 450, Mega 475, Elite 500, or Elite 600

Full Bracket and Pro Modes

See Dial-ins and Delays at the same time

Backlit Keypad and Screen

Burn-out Timer

Separate I/O board to simplify wiring

Tap Up, Down, and Multi-tap

Driver’s Reaction Tester

9 pass memory Replay Tach

Three 4 Stage Timers

Shift up to 5 time by RPM or Time

5 Push modes

7 independent outputs:

Transbrake

Starting Line Enhancer

Line Lock

Timer 1 (40 Amp)

Timer 2 (40 Amp)

Timer 3 (40 Amp)

Shift (40 Amp)

All Outputs are fused

Status LED’s on I/O board

* Z-Force is a registered trade mark of K&R Performance Engineering

1111BR-BR-DV - Black Dual View Board with RED LED

 1111BR-BB-DV - Black Dual View Board with BLUE LED

 1111BR-BG-DV - Black Dual View Board with GREEN LED

 1111BR-BO-DV - Black Dual View Board with ORANGE LED

 1111BR-BW-DV - Black Dual View Board with WHITE LED
